RectiLume White 220 width

Overview
Related Products

The RectiLume series features 72W dynamic-white LED luminaires with a sleek 220x280mm profile and completely concealed wiring for flawless architectural integration. Its advanced tunable-white technology enables smooth color temperature transitions between 2200K-3000K (warm ambiance) and 2700K-6500K (adjustable white), allowing dynamic lighting adjustments to suit any space requirement. Powered by WITOP's latest-generation LED array with optimized candela and lumen distribution, it delivers precision lighting for both narrow-beam and wide-beam applications. The Rectilux exemplifies versatility with configurable options including wall-wash/flood optics, multiple mounting solutions, control accessories, and standard finishes to complement any design scheme.
·3 SDCM color tolerance ensuring consistent light color.
·Sturdiness and durability 6063-T5 high density extruded aluminium alloy.
·Optical grade PMMA lens and high-strength and impact-resistant silk screen tempered glass .
·Length, height, beam angle, color temperature, color rendering index (CRI), and luminous efficacy etc are all custom-made.
Specific details
Power:DC24V/48V
Color:White
Color Temperature Options:2700K,3000K,3500K,4000K,5000K,5700K,6500K
Power consumption:72W
Beam Angle:3°,5°,8°,10°,20°,30°,60°
Lumen Maintenance:L70>50,000hrs
Color Rendering:CRI80/CRI90 optional
Luminous Efficacy:120lm/W,High LM dimming available (PWM)
Dimming:ON/OFF, 0-10V, DALI, TRIAC, PWM
IP Rating:IP66
Warranty:5years

Applications
Architectural Facade Lighting
Commercial and Advertising Lighting
Landscape and Garden Lighting
Industrial and Functional Area Lighting
Same model

Model No	Input Voltage	Size(mm)	Beam angle	power
WTP-OL166W	DC24V/48V	166*45	3°,5°,8°,10°,20°,30°,60°	24W
WTP-OL217W	DC24V/48V	217*45	3°,5°,8°,10°,20°,30°,60°	48W
WTP-RL160W	DC24V/48V	160*215	3°,5°,8°,10°,20°,30°,60°	36W
WTP-RL220W	DC24V/48V	220*280	3°,5°,8°,10°,20°,30°,60°	72W
