OrbisLume White 217 width

Overview
Related Products

The OrbisLume series features IP66-rated luminaires designed to accentuate landscapes, trees, columns, monuments, and architectural details. Its standout feature is customizable color temperature, offering versatile ranges: 2200K-3000K or 2700K-6500K.This dynamic tunability empowers designers and end-users to transform space atmospherics—whether adapting to different times of day or varying functional requirements.Enhanced Configuration Options Including: Interchangeable optics for both flood lighting and accent illumination; Optional diffuser lenses and control accessories.Corrosion-resistant variants engineered for demanding environments (industrial/chemical/coastal applications).
·3 SDCM color tolerance ensuring consistent light color.
·Sturdiness and durability 6063-T5 high density extruded aluminium alloy
·Optical grade PMMA lens and high-strength and impact-resistant silk screen tempered glass .
·Length, height, beam angle, color temperature, color rendering index (CRI), and luminous efficacy etc are all custom-made.

Specific details
Power:DC24V/48V
Color:White
Color Temperature Options:2700K,3000K,3500K,4000K,5000K,5700K,6500K
Power consumption:48W
Beam Angle:3°,5°,8°,10°,20°,30°,60°
Lumen Maintenance:L70>50,000hrs
Color Rendering:CRI80/CRI90 optional
Luminous Efficacy:120lm/W,High LM dimming available (PWM)
Dimming:ON/OFF, 0-10V, DALI, TRIAC, PWM
IP Rating:IP66
Warranty:5years

Applications

Architectural and Landscape Lighting
Commercial and Retail Lighting
Landscape and Garden Lighting
Industrial and Area Lighting

Same model

Model No	Input Voltage	Size(mm)	Beam angle	power
WTP-OL166W	DC24V/48V	166*45	3°,5°,8°,10°,20°,30°,60°	24W
WTP-OL217W	DC24V/48V	217*45	3°,5°,8°,10°,20°,30°,60°	48W
WTP-RL160W	DC24V/48V	160*215	3°,5°,8°,10°,20°,30°,60°	36W
WTP-RL220W	DC24V/48V	220*280	3°,5°,8°,10°,20°,30°,60°	72W
